Paper Processing Machinery Automatic Pulp Making Machine Waste Paper Recycled D Type Hydra Pulper Machine
OCC Stock Preparation Pulper Machine Paper Processing Machinery
This equipment adopts D type structure, which improves the work efficiency, and it can be used for pulping waste paper & wet strength paper.
New type energy-saving VOKES rotor strengthens hydraulic circulation and fiber relief.
D type structure changes pulp flow ways, make contact between pulp and rotor more quick and frequent. The mechanical action is enhance, pulping time is shortened so that the capacity is improved.
Pulp chamber of rotor is higher than the under surface of pulper barrel, form a low pressure area around rotor to collect heavy impurities, reduce wear to cutter head and sieve plate. So that can prolong the rotor and sieve plate service life.
Adjustable gap between rotor and sieve plate ensures the pulping effect.
| Model | ZDSD23 | ZDSD24 | ZDSD25 | ZDSD26 | ZDSD27 | ZDSD28 | ZDSD29 | ZDSD30 | ZDSD31 | ZDSD32 | ZDSD33 | ZDSD34 | ZDSD35 | ZDSD36 | ZDSD37 |
| Volume (m³) | 5 | 10 | 15 | 20 | 25 | 30 | 35 | 40 | 45 | 50 | 60 | 70 | 90 | 120 | 140 |
| Concentration (%) | 3-5 | ||||||||||||||
| Capacity (t/d) | 30-60 | 40-100 | 80-120 | 140-180 | 180-230 | 230-280 | 270-320 | 300-370 | 350-400 | 400-450 | 460-550 | 550-650 | 650-800 | 800-1000 | 1000-2000 |
| Motor Power(KW) | 75 | 110 | 160 | 185 | 220 | 280 | 315 | 355 | 400 | 450 | 560 | 630 | 900 | 1100 | 1250 |
