Pulping Equipment Double Disc Refiner Machine Paper Pulp Making Machine Production Line
Double disc refiner
Double Disc Refiner is used for continuously pulping chemical wood pulp, mechanical pulp, and recycled pulp under consistency of 3%-5%, which is an ideal pulping equipment.
The specially designed moving disc can be automatically aligned under the action of pulp.
According to the refining requirements of the grinding area, the clearance of the grinding area is adjusted by the electromechanical adjusting device.
The integrated special maintenance device is adopted to make the replacement of grinding plate convenient and quick.
High strength welding structure makes operation reliable and stable.
| Model | PM20 | PM26 | PM34 | PM42 |
| Diameter of Disc (in) | 20-24 | 26-30 | 34-38 | 42-48 |
| Minimum flow(L/Min) | 400 | 800 | 1500 | 2500 |
| Maximum flow (L/min) | 2500 | 5000 | 10000 | 15000 |
| Motor Power (kw) | 315 | 500 | 900 | 1800 |
