The reeling cylinder of paper reel is one of its core components. It is responsible for winding paper and drives the paper web to wind through friction.
The reel cylinder of a paper reel is usually cast from gray iron, the inner wall of the cylinder is polished, and the outer circle is polished to ensure a smooth surface. The reel cylinder is fixed to the cylinder cover by bolts, and the dynamic balance needs to be corrected after assembly. The entire reel cylinder is supported on the frame by bearings on the operating side and the transmission side, and the transmission end is connected to the transmission system of the paper machine to drive the rotation.
The main function of the reel cylinder of a paper reel is to wind paper. In order to cool and shape the paper web and humidify it, and eliminate static electricity on the paper web, the operating side of the reel cylinder is equipped with an air-water joint for connecting cooling water to spray directly onto the inner wall of the reel cylinder to cool the cylinder. In addition, there is an air inlet, and when actually needed, compressed air can be introduced through the operating console to achieve pressurized drainage, thereby further improving the cooling effect.
